Smart Automation Multimedia Panel

Home/Office Audio System

All-in-one audio amplifier system connects up to 8 speakers, max. power rate reaches up to 240W. 2-zones are available, can play different music and control volume separately. Locally playing music from internal storage (16GB) and on-board memory card (max. 256GB), remotely playing through Wi-Fi/DLNA, Bluetooth connection. Aux audio input and output, can connect your traditional audio equipment. With a HDMI output, it can connect to your TV as a multimedia system.

Smart Home Automation Hub

The system is also a smart home automation hub with seamlessly integration of Tuya MiJia Aqara LifeSmart. You’re able to control smart devices and home appliances through the panel. Supporting scene control and management, it’s the right choice if you need a central control panel for your existing home automation system.

8-inch Smart Android Tablet

8-inch HD screen tablet with Android OS, 2GB+16GB hardware design ensure the system runs smoothly. You’re able to install your own apps, so that you can use it as a tablet. It supports both Wi-Fi and Ethernet network connection. Unlike Wi-Fi wireless is vulnerable to signal interference, by using wired network connection, your system will become more stable and always stay online.

Product highlight

• 8-inch IPS high definition screen
• Rockchip quadcore ARM powerful processor
• 2GB RAM + 16GB ROM hardware design
• Multimedia audio system supports DLNA, Airplay, Qplay
• 8-channel audio amplifier, max. 240Watt power rate
• 2 audio zones, control and play music separately
• 1CH aux audio input and 1CH aux audio output
• RS485 peripheral to control other panels
• Tuya Mijia Aqara LifeSmart home automation integration
• Play music via Bluetooth, local internal storage, microSD card
• Remotely control and play music through Tuya Smart app
• Standard gang dimension design to fit universal 2-gang box

Product Specification

• Model: TUYA-U9
• Power input: AC90~240V
• Display: 8-inch IPS HD screen
• Display resolution: 1280*800
• Video output: HDMI
• OS: Android 6.0
• CPU: Rockchip Quad-Core ARM
• Hardware: 2GB RAM
• Storage: 16GB ROM
• Audio Output: 8*30W
• Audio impedance: 8Ohm
• Audio Input: 2-channels
• Control interface: RS485
• Wi-Fi: IEEE802.11 b/g/n 2.4G
• Ethernet: RJ45 10/100Mbps
• Bluetooth: 4.0 10 meters
• External storage: microSD card slot (max. 128GB)
• IoT platforms: Tuya, Mijia, Aqara, LifeSmart
• Color: Grey/Champagne
• Tablet dimension: 195*144*5.8mm
